Features
["Cast-Aluminum Construction \u2014 built to last with rugged cast-aluminum construction, designed for maximum durability and corrosion resistance", "Faster Filling \u2014 Double piston action delivers premium performance with 20 gallons every 100 strokes, saving time and reducing physical strain", "No Electricity Needed \u2014 ideal for low-volume applications where access to power is not available or required, allowing for stationary use or complete mobility", "Consistent Performance \u2014 onboard vacuum breaker facilitates uninterrupted performance and creates smoother flow at the discharge", "Theft Prevention \u2014 padlock-compatible handle adds security to protect your investment", "Prevents Spillage \u2014 included discharge nozzle storage and anti-siphon technology prevent accidental fuel spillage, eliminating mess enhancing safety", "Fluid Compatibility \u2014 designed for daily use with gasoline, diesel, heptane, kerosene, Stoddard solvents, light oils, and mineral spirits"]
Accessories
Description
Fill-Rite's piston pump series are built with tough cast-iron construction and are ideal for low volume commercial or recreational transfer.
General Attributes
| Max Flowrate | 20 Gal / 75 Liters Per 100 Strokes |
|---|---|
| Power Type | Hand-Operated |
| Compatible Fluids | Diesel, Gasoline, Kerosene, Mineral Spirits, Heptane, Stoddard Solvents |
| Inlet Size / Connection / Thread | 1 " / Female / NPT |
| Outlet Size / Connection / Thread | 0.75 " / Female / NPT |
| Mounting Size / Thread / Type | 2" / NPT / Bung Mount |
| Duty Cycle (min) | Continuous Duty |
| Assembled Product Height x Width x Depth (in.) | 20 x 6.5 x 9.25 |
| Assembled Product Weight (lbs.) | 11.2 |
| Package Height x Width x Depth (in.) | 8.56 x 23.38 x 8.63 |
| Gross Weight (lbs.) | 13.80000 lbs |
| Less Than Load (LTL) Freight | Yes |
