0.03 - 0.3 GPM Electronic 1/4" NPT Stainless-Steel Meter with Reed Switch and Stainless-Steel Rotors (NOT FOR FLUID RESALE)

Scraped SKU: TM02DSRSAXKE1BB Price: 1,493.00 USD 2026-06-05 18:19:50

Attributes

Features Html
Precise Measurement: Accuracy in measuring flow rates, ensuring reliable data for various fluids and applications., Compact Design: Ideal for installations where space is limited, maximizing efficiency without compromising performance., Versatile Compatibility: Compatible with a wide range of fluids, from water and oils to chemicals, making it adaptable across industries such as manufacturing, automotive, and many others., Durable Construction: Built to withstand the harshest environments, the Stainless-Steel body of this meter boasts a robust construction that ensures durability and longevity., Cost-Effective Solution: Cost-effective flow measurement solution, offering a balance of performance, reliability, and affordability, delivering long-term value for businesses of all sizes., Low Maintenance: Low maintenance in nature, as it only contains two moving parts and there is no metal-to-metal contact virtually eliminating any wear. reducing maintenance expenses over time., Accurate Readouts: Provides precise, real-time flow measurements, enabling users to monitor and control fluid flow with confidence, ultimately improving process efficiency.

Description

The TM02DSRSAXKE1BB is a stainless-steel E85 & Low Caustics transfer meter equipped with a Reed Switch and 1/4" NPT threads and is designed to register 0.03 - 0.3 gallons per minute at 0.05% repeatability.

Specifications

Inlet Size / Connection / Thread0.25 " / Female / NPT
Outlet Size / Connection / Thread0.25 " / Female / NPT
Repeatability (+/- %)0.5 %
Linearity (+/- %) over 10:1 Turndown2
Max Operating Pressure (PSI)1500
Compatible FluidsHeptane, Hexane, Ethylene Glycol, Stoddard Solvents, E85, Benzaldehyde, Formaldehyde, Xylene, Vinegar
Housing Materials316 Stainless Steel
Seal MaterialsTeflon
Bearing MaterialsTeflon
Wetted Materials316 Stainless Steel
Strainer Mesh Size (Micron)N/A
Assembled Product Weight (lbs.)6.5
Package Height x Width x Depth (in.)5 x 5 x N/A
Gross Weight (lbs.)6.50000 lbs
Less Than Load (LTL) FreightYes
