3" BSPP 151-1135 LPM Electronic Custody Transfer Rated Transmission Fluid and Oils Meter

Scraped 2026-05-20 04:07:36

Features

["Precision Engineering: Our oval gear flow meter is crafted with precision engineering, ensuring accurate and repeatable measurements. It excels in providing dependable data for custody transfer, giving you confidence in your transactional processes.", "Robust Construction: Built to withstand the harshest environments, the stainless-steel body of this meter boasts a robust construction that ensures durability and longevity.", "High Accuracy: Designed to minimize uncertainties in measurement, making it a trustworthy instrument for custody transfer applications where precision is paramount.", "Easy Installation and Maintenance: Save time and resources with our user-friendly design. The installation process is straightforward, and routine maintenance is a breeze, ensuring minimal downtime for your operations.", "Compliance: Our oval gear flow meter meets industry standards and compliances for custody transfer applications, providing peace of mind when it comes to regulatory requirements.", "Cost Efficiency: By investing in our custody transfer flow meter, you are making a cost-effective choice. Its longevity, low maintenance requirements, and high accuracy contribute to overall cost savings.", "Reliable Data for Transactions: Trust is essential in custody transfer transactions, and our flow meter provides the reliability you need. Eliminate uncertainties and ensure fair and accurate transactions every time.", "Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently."]

Accessories

    Description

    Fill-Rite’s TS30 Electronic Series of oval gear fluid transfer meters are ideal for mobile or stationary high-volume custody transfer applications.

    General Attributes

    Flowrate Range (GPM) 151-1135 LPM
    Inlet Size / Connection / Thread 3 " / Female / BSPP
    Outlet Size / Connection / Thread 3 " / Female / BSPP
    Repeatability (+/- %) 0.05 %
    Linearity (+/- %) over 5:1 Turndown .175
    Linearity (+/- %) over 10:1 Turndown .3
    Linearity (+/- %) over 30:1 Turndown .5
    Max Operating Pressure (PSI) 400
    Operating Temperature Range (°F) -40 - 180°F / -40 - 82°C
    Power Source Electrical
    Cable Length (ft) 3
    Cable Gauge (GA) 24
    Pulse Output Yes
    Compatible Fluids Transmission Fluid
    Housing Materials Anodized Aluminum
    Seal Materials Viton
    Bearing Materials Carbon Graphite
    Wetted Materials Anodized Aluminum Fluorocarbon PPS
    Strainer Mesh Size (Micron) N/A
    Gross Weight (lbs.) 38.00000 lbs
    Less Than Load (LTL) Freight Yes
