Attributes
| Features Html | Precise Measurement: Accuracy in measuring flow rates, ensuring reliable data for various fluids and applications., Compact Design: Ideal for installations where space is limited, maximizing efficiency without compromising performance., Versatile Compatibility: Compatible with a wide range of fluids, from water and oils to chemicals, making it adaptable across industries such as manufacturing, automotive, and many others., Durable Construction: Built to withstand the harshest environments, the Stainless-Steel body of this meter boasts a robust construction that ensures durability and longevity., Cost-Effective Solution: Cost-effective flow measurement solution, offering a balance of performance, reliability, and affordability, delivering long-term value for businesses of all sizes., Low Maintenance: Low maintenance in nature, as it only contains two moving parts and there is no metal-to-metal contact virtually eliminating any wear. reducing maintenance expenses over time., Accurate Readouts: Provides precise, real-time flow measurements, enabling users to monitor and control fluid flow with confidence, ultimately improving process efficiency. |
|---|
Description
The TM03DSHEAXKE4HB is a stainless-steel E85 & Low Caustics transfer meter equipped with a Hall Effect Sensor and 3/8" NPT threads and is designed to register 0.3-3 gallons per minute at 0.05% repeatability.
Specifications
| Flowrate Range (GPM) | 0.3-3GPM |
|---|---|
| Inlet Size / Connection / Thread | 0.375 " / Female / NPT |
| Outlet Size / Connection / Thread | 0.375 " / Female / NPT |
| Repeatability (+/- %) | 0.5 % |
| Linearity (+/- %) over 10:1 Turndown | 1 |
| Max Operating Pressure (PSI) | 1500 |
| Compatible Fluids | Heptane, Hexane, Ethylene Glycol, Stoddard Solvents, E85, Benzaldehyde, Formaldehyde, Xylene, Vinegar |
| Housing Materials | 316 Stainless Steel |
| Seal Materials | Teflon |
| Strainer Mesh Size (Micron) | N/A |
| Assembled Product Weight (lbs.) | 1.57 |
| Package Height x Width x Depth (in.) | 5 x 5 x N/A |
| Gross Weight (lbs.) | 1.57000 lbs |
| Less Than Load (LTL) Freight | Yes |
