151-1135 LPM 5 Digit Mechanical Custody Transfer Rated Fuel Meter

Scraped SKU: TS30AV04ALCBMXAXXN Price: 7,262.00 USD 2026-06-05 18:18:32

Attributes

Features Html
Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently., Precision Engineering: Our oval gear flow meter is crafted with precision engineering, ensuring accurate and repeatable measurements. It excels in providing dependable data for custody transfer, giving you confidence in your transactional processes., Robust Construction: Built to withstand the harshest environments, the anodized aluminum body of this meter boasts a robust construction that ensures durability and longevity., High Accuracy: Designed to minimize uncertainties in measurement, making it a trustworthy instrument for custody transfer applications where precision is paramount., Easy Installation and Maintenance: Save time and resources with our user-friendly design. The installation process is straightforward, and routine maintenance is a breeze, ensuring minimal downtime for your operations., Compliance: Our oval gear flow meter meets industry standards and compliances for custody transfer applications, providing peace of mind when it comes to regulatory requirements., Cost Efficiency: By investing in our custody transfer flow meter, you are making a cost-effective choice. Its longevity, low maintenance requirements, and high accuracy contribute to overall cost savings., Reliable Data for Transactions: Trust is essential in custody transfer transactions, and our flow meter provides the reliability you need. Eliminate uncertainties and ensure fair and accurate transactions every time., Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently.
Series Codets30av04alcbmxaxx-ts30av04alcbmxaxx
Series Name151-1135 LPM 5 Digit Mechanical Custody Transfer Rated Fuel Meter
Series Urlhttps://www.fillrite.com/ts30av04alcbmxaxx-ts30av04alcbmxaxx

Description

The TS30AV04ALCBMXAXXN is a 100% non-ferrous 5-digit mechanical Standard Fuels transfer meter. This meter is equipped with 3" NPT threads and is designed to register 151-1135 liters per minute at 0.05% repeatability.

Specifications

Flowrate Range (GPM)151-1135 LPM
Inlet Size / Connection / Thread3 " / Female / NPT
Outlet Size / Connection / Thread3 " / Female / NPT
Repeatability (+/- %)0.05 %
Linearity (+/- %) over 5:1 Turndown.175
Linearity (+/- %) over 10:1 Turndown.3
Linearity (+/- %) over 30:1 Turndown.5
Max Operating Pressure (PSI)150
Operating Temperature Range (°F)-40 - 180°F / -40 - 82°C
Power SourceMechnical
Power TypeN/A
Display TypeMechanical
Display Digits5
Compatible FluidsDiesel, Gasoline, Kerosene, Non-Potable Water, Light Oils, Biodiesel
Housing MaterialsAnodized Aluminum
Seal MaterialsViton
Bearing MaterialsCarbon Graphite
Wetted MaterialsAnodized Aluminum Fluorocarbon PPS
Assembled Product Weight (lbs.)113
Package Height x Width x Depth (in.)20 x 18 x N/A
Gross Weight (lbs.)113.00000 lbs
Less Than Load (LTL) FreightYes
