151-908 LPM 5 Digit Mechanical Custody Transfer Rated DEF and High Caustics Fluid Meter

Scraped SKU: TS30CV04CLCCMXBXXN Price: 15,750.00 USD 2026-06-05 18:18:42

Attributes

Features Html
Precision Engineering: Our oval gear flow meter is crafted with precision engineering, ensuring accurate and repeatable measurements. It excels in providing dependable data for custody transfer, giving you confidence in your transactional processes., Robust Construction: Built to withstand the harshest environments, the stainless-steel body of this meter boasts a robust construction that ensures durability and longevity., High Accuracy: Designed to minimize uncertainties in measurement, making it a trustworthy instrument for custody transfer applications where precision is paramount., Easy Installation and Maintenance: Save time and resources with our user-friendly design. The installation process is straightforward, and routine maintenance is a breeze, ensuring minimal downtime for your operations., Compliance: Our oval gear flow meter meets industry standards and compliances for custody transfer applications, providing peace of mind when it comes to regulatory requirements., Cost Efficiency: By investing in our custody transfer flow meter, you are making a cost-effective choice. Its longevity, low maintenance requirements, and high accuracy contribute to overall cost savings., Reliable Data for Transactions: Trust is essential in custody transfer transactions, and our flow meter provides the reliability you need. Eliminate uncertainties and ensure fair and accurate transactions every time., Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently.
Series Code94-605-lpm-5-digit-mechanical-custody-transfer-rated-def-and-high-caustics-fluid-meter
Series Name151-908 LPM 5 Digit Mechanical Custody Transfer Rated DEF and High Caustics Fluid Meter
Series Urlhttps://www.fillrite.com/94-605-lpm-5-digit-mechanical-custody-transfer-rated-def-and-high-caustics-fluid-meter

Description

The TS30CV04CLCCMXBXXN is a stainless-steel 5-digit mechanical DEF and Caustics over 50% concentration transfer meter. This meter is equipped with 3" ANSI Flanges and is designed to register 151-908 liters per minute at 0.05% repeatability.

Specifications

Flowrate Range (GPM)151-908 LPM
Inlet Size / Connection / Thread3 " / ANSI / ANSI
Outlet Size / Connection / Thread3 " / ANSI / ANSI
Repeatability (+/- %)0.05 %
Linearity (+/- %) over 5:1 Turndown.175
Linearity (+/- %) over 10:1 Turndown.3
Linearity (+/- %) over 30:1 Turndown.5
Operating Temperature Range (°F)-40 - 180°F / -40 - 82°C
Power SourceMechnical
Display TypeMechanical
Display Digits5
Compatible FluidsDEF
Housing Materials316 Stainless Steel
Seal MaterialsTeflon
Bearing MaterialsTeflon
Wetted Materials316 Stainless Steel PPS PTFE
Strainer Mesh Size (Micron)N/A
Gross Weight (lbs.)117.00000 lbs
Less Than Load (LTL) FreightYes
