40-300 GPM 5 Digit Mechanical Custody Transfer Rated Transmission Fluid and Oils Meter with Strainer and Air Eliminator

Scraped SKU: TS30AV06AGCIMXAS2N Price: 9,596.00 USD 2026-06-05 18:18:54

Attributes

Features Html
Precision Engineering: Our oval gear flow meter is crafted with precision engineering, ensuring accurate and repeatable measurements. It excels in providing dependable data for custody transfer, giving you confidence in your transactional processes., Robust Construction: Built to withstand the harshest environments, the anodized aluminum body of this meter boasts a robust construction that ensures durability and longevity., High Accuracy: Designed to minimize uncertainties in measurement, making it a trustworthy instrument for custody transfer applications where precision is paramount., Easy Installation and Maintenance: Save time and resources with our user-friendly design. The installation process is straightforward, and routine maintenance is a breeze, ensuring minimal downtime for your operations., Compliance: Our oval gear flow meter meets industry standards and compliances for custody transfer applications, providing peace of mind when it comes to regulatory requirements., Cost Efficiency: By investing in our custody transfer flow meter, you are making a cost-effective choice. Its longevity, low maintenance requirements, and high accuracy contribute to overall cost savings., Reliable Data for Transactions: Trust is essential in custody transfer transactions, and our flow meter provides the reliability you need. Eliminate uncertainties and ensure fair and accurate transactions every time., Enhanced Operational Efficiency: The efficiency of your operations is directly impacted by the precision of your measurements. Improve your overall operational efficiency with a flow meter designed to deliver accurate results consistently.
Series Codets30av06agcimxas2-ts30av06agcimxas2
Series Name40-300 GPM 5 Digit Mechanical Custody Transfer Rated Transmission Fluid and Oils Meter with Strainer and Air Eliminator
Series Urlhttps://www.fillrite.com/ts30av06agcimxas2-ts30av06agcimxas2

Description

The TS30AV06AGCIMXAS2N is a 100% non-ferrous 5-digit mechanical Automatic Transmission Fluid and High Temp Fluid transfer meter. This meter is equipped with 3" NPT threads and is designed to register 40-300 gallons per minute at 0.05% repeatability.

Specifications

Flowrate Range (GPM)40-300 GPM
Inlet Size / Connection / Thread3 " / Female / NPT
Outlet Size / Connection / Thread3 " / Female / NPT
Repeatability (+/- %)0.05 %
Linearity (+/- %) over 5:1 Turndown.175
Linearity (+/- %) over 10:1 Turndown.3
Linearity (+/- %) over 30:1 Turndown.5
Max Operating Pressure (PSI)150
Operating Temperature Range (°F)-40 - 180°F / -40 - 82°C
Power SourceMechnical
Power TypeN/A
Display TypeMechanical
Display Digits5
Compatible FluidsGear Oils, Motor Oils, Hydraulic Oils, Transmission Fluid, Lube Oils
Housing MaterialsAnodized Aluminum
Seal MaterialsViton
Bearing MaterialsCarbon Graphite
Wetted MaterialsAnodized Aluminum Fluorocarbon PPS
Strainer Mesh Size (Micron)20
Assembled Product Weight (lbs.)52
Package Height x Width x Depth (in.)26 x 23 x N/A
Gross Weight (lbs.)52.00000 lbs
Less Than Load (LTL) FreightYes
